🎨 From ₹150 / part

Powder Coating

Electrostatic powder coating in 12 standard RAL colours. Sandblast prep and phosphate treatment included. Corrosion-resistant, vibrant, and durable.

What is Powder Coating?

Powder coating is a dry finishing process where electrostatically charged powder particles are sprayed onto a grounded metal part. The part is then cured in an oven at 180°C, melting the powder into a smooth, hard film that bonds chemically to the metal surface.

The result is a finish that's 2–3× thicker and more durable than liquid paint, with excellent resistance to chipping, scratching, corrosion, and UV fading. FYORD's full-service process includes surface prep — you send bare metal, we return a finished part.

  • Sandblasting + iron phosphate wash included in price
  • 60–100 µm film thickness — no drips, no runs
  • Cure temperature 180°C · 20-minute oven cycle
  • Suitable for MS, SS, aluminium, and cast iron
  • Salt-spray tested: 500 hours minimum (RAL 9005 Black)
Powder coated metal parts

Process Specifications

🎨
Standard Colours
12 RAL
Custom RAL on request (MOQ 5)
📏
Film Thickness
60–100 µm
Measured per ISO 2178
🌡️
Cure Temperature
180°C
20-minute oven dwell
📐
Max Part Size
1200 × 800
mm · larger parts quoted
📦
Lead Time
1–2 days
After fabrication
🛡️
Salt Spray
500 h
ISO 9227 · per RAL 9005

12 Standard RAL Colours — In Stock

All standard colours are in stock and available same-week. Custom RAL colours available with 5-piece minimum.

Jet Black
RAL 9005
Traffic White
RAL 9016
Traffic Red
RAL 3020
Gentian Blue
RAL 5010
Emerald Green
RAL 6001
Saffron Yellow
RAL 1017
Yellow Orange
RAL 2000
Window Grey
RAL 7040
Basalt Grey
RAL 7012
Red Violet
RAL 4002
Chocolate Brown
RAL 8017
Aluminium Silver
RAL 9006

Preparing Parts for Powder Coating

🕳️ Hanging Holes

Include a 4–6 mm hanging hole in a hidden location (inside flange, corner tab). Parts must be hung in the oven — parts without hanging points incur a ₹50 jig-and-fixture charge.

🔩 Mask Threads & Bores

Mark any tapped holes, precision bores, or mating surfaces that must remain uncoated. We apply silicone plugs before coating. Specify on your order notes.

🔲 Weld Spatter

Remove all weld spatter and grinding marks before sending. Our sandblast removes mill scale and rust, but large spatter shows through the finish coat.

📐 Thin Edges

Powder builds up slightly thicker on sharp edges. If edge sharpness is critical (knife edges, sliding fits), specify "edge control" and we'll back-off or hand-sand after curing.

💡 Pro tip: Order laser cutting + bending + powder coating together. We handle the full flow internally — no inter-factory logistics, and your total lead time drops by 1–2 days.

Ready to finish your parts?

Add powder coating to your order at checkout, or send bare parts directly for standalone finishing.
